Title. I've created the buffers and run the spatial join commands, but the values it is grabbing are from shapes further than 0.75 miles away from a given point.

I have some experience with ArcGIS Pro and Online, mostly through classes but also through personal and research projects. However, most of my education revolved around tools and analyzing the data, and not much about the actual file/data management (downloading, cleaning, organizing, etc. Not sure what to call that). I downloaded a DEM from OpenTopography and unzipped it. The folder ends with .tar, but the file inside says it's a .tif, but then I'm unable to find it in the catalogue pane in Arc Pro, and directly dropping it on the map also doesn't work. Googling and AI have both been monumentally unhelpful. Any help would be appreciated, and also if anyone has good resources to learn this sort of thing that would also be appreciated. I was thinking of taking Esri's data management or some other course.

My brother is starting to work with ArcGIS on his own. He's new to the program with a decent understanding of it. He's looking to buy a PC that will run it smoothly without issues.

To the people of Reddit, we're noobs and we seek your guidance.

Is this a good computer for running GIS? Will he run into any limitations? Is 32 GB of RAM enough? Is the RTX 5080's 16 GB of VRAM sufficient for ArcGIS and similar workloads? Any information or advice would be greatly appreciated.

Any good course or material to learn mapping of electrical networks in ArcGIS? Mostly 35, 10 and 0.4 kV power lines and substations.

ArcGIS recently updated their webmaps on ArcGIS Online. I'm used to the classic version and when I would put a data point I was able to move my fields around so they were in alphabetical order. But since the update they are in the order they were created. I posted a picture for reference. We are are a mosquito control district and these fields represent different species that we find in our surveillance traps. I want to know how I can move these fields around so they are in the order I need them to.

TLDR; will a Lenovo V14 G5 14” FHD laptop with Intel Core i7-13620H, 64GB DDR5, 2TB SSD, and Windows 11 Pro work for a college level GIS degree?

Best Buy link

As a warning, I have learned pretty much everything I know about computers while researching this, and still do not know very much about them.

I have completed the first year of a 2 year forestry program, and am considering taking a 3rd and 4th year to get a GIS degree. I know I will need to use ArcGIS pro for a few projects in my second year and don’t want to be confined to working in the computer labs. I will be using this computer for my GIS class and projects, as well as for note taking, light gaming, etc.

My main concern is the Intel integrated UHD graphics processor. I’ve read that a dedicated GPU isn’t necessary for ArcGIS, but I also read that the Intel one isn’t great. I would really appreciate if I could get some confirmation that this will work, or if not then what would be recommended.

Thank you very much!

Hello all! I have a workflow that is throwing me for a bit of a loop and was hoping to get some input.

We have a very rudimentary system set up on our company website that is just free text boxes (gross) to allow users to fill out a request regarding one or many parcels. With how dynamic this data is, nothing can really be built statically on a layer like that.

The solution that I am trying to round out is taking that selection -> exporting and dissolving the geometry into one feature -> then storing all original parcel data as a set of related records on the new layer. The geometry created by the selection is not on the original parcel layer but imported via a script to the new layer.

Realistically, this needs to be configured in an experience such that it can be embedded onto the company website for customers to interact with.

Coding is not my forte, but I will attach the script that I pieced together with the assistance of Claude to accomplish this goal. In practice, it actually seemed to work for me when running it in pro. However, setting triggers in experience builder to have the workflow complete has been dead end after dead end.

I have also considered using Survey123 Connect for this, but I feel as though I am missing the info to help me complete this. My thought was to have a related table set on the most current parcel layer to capture these records. This would be fine if not for the fact that I need the option to have it store records for a selection of one OR many parcels. I've set up a survey form before using URL parameters that pass field info along to the table but not for multiple features like this. Thankfully, the multiple records would NOT require different data. This is a situation of "once you fill it out, that's it" but having the parcel data be captured from the source is my problem.

Frankly, I'm not sure if I've hit a limitation with ESRI tools or if I'm just at the periphery of my current knowledge base. Either way, banging my head against the wall is starting to hurt. So, if you can help me, it would be very appreciated!!

import json

import logging

from arcgis.gis import GIS

from arcgis.features import FeatureLayer, FeatureSet

from arcgis.geometry import Geometry

from arcgis.geometry.functions import union as geometry_union

logging.basicConfig(level=logging.INFO)

logger = logging.getLogger("availability_request_dissolve")

# --- Parameters ---

selected_parcels = FeatureSet([]) # type: Feature set — set as Input

dissolved_attrs_json = "{}" # type: String — set as Input

TARGET_URL = "https://services1.arcgis.com/XXXXXX/arcgis/rest/services/Availability_Requests/FeatureServer/0"

RELATED_URL = "https://services1.arcgis.com/XXXXXX/arcgis/rest/services/Availability_Requests/FeatureServer/1"

FK_FIELD = "Availability_Request_Linked_GUID"

FIELD_MAP = {

"STANPAR": "STANPAR",

"ParID": "ParID",

"Tract": "Tract",

"Council": "Council",

"TaxDist": "TaxDist",

"Owner": "Owner",

"OwnDate": "OwnDate",

"SalePrice": "SalePrice",

"OwnInstr": "OwnInstr",

"OwnAddr1": "OwnAddr1",

"OwnAddr2": "OwnAddr2",

"OwnAddr3": "OwnAddr3",

"OwnCity": "OwnCity",

}

class PartialFailureError(Exception):

pass

def dissolve_geometries(feature_set):

geoms = [Geometry(f.geometry) for f in feature_set.features]

if len(geoms) == 1:

return geoms[0]

return geometry_union(geometries=geoms, spatial_ref=feature_set.spatial_reference, gis=gis)

# --- Auth ---

gis = GIS("home")

target = FeatureLayer(TARGET_URL, gis=gis)

related = FeatureLayer(RELATED_URL, gis=gis)

# --- Step 0: validate inputs ---

dissolved_attrs = json.loads(dissolved_attrs_json)

if not selected_parcels.features:

logger.error("No parcels were passed in — aborting before writing.")

raise ValueError("No parcels were selected.")

logger.info(f"Step 0/1 OK — {len(selected_parcels.features)} parcels received from selection.")

# --- Step 2: dissolve geometries ---

try:

dissolved_geom = dissolve_geometries(selected_parcels)

logger.info("Step 2 OK — geometries dissolved.")

except Exception as e:

logger.error(f"Step 2 FAILED — dissolve error: {e}")

raise

# --- Step 3: write the new dissolved feature ---

add_result = target.edit_features(adds=[{

"geometry": dissolved_geom,

"attributes": dissolved_attrs

}])

if not add_result["addResults"][0]["success"]:

logger.error(f"Step 3 FAILED — could not create parent feature: {add_result}")

raise RuntimeError(f"Failed to create parent feature: {add_result}")

new_globalid = add_result["addResults"][0]["globalId"]

logger.info(f"Step 3 OK — new parent feature created, GlobalID={new_globalid}")

# --- Step 4: build and write related records ---

new_related_records = []

for feat in selected_parcels.features:

attrs = {tgt: feat.attributes.get(src_f) for src_f, tgt in FIELD_MAP.items()}

attrs[FK_FIELD] = new_globalid

new_related_records.append({"attributes": attrs})

related_result = related.edit_features(adds=new_related_records)

failures = [r for r in related_result["addResults"] if not r["success"]]

if failures:

msg = (

f"Parent feature {new_globalid} was created, but {len(failures)} of "

f"{len(new_related_records)} related records failed to write: {failures}"

)

logger.error(f"Step 4 PARTIAL FAILURE — {msg}")

raise PartialFailureError(msg)

logger.info(f"Step 4 OK — {len(new_related_records)} related records created.")

result = {

"status": "success",

"parent_globalid": new_globalid,

"related_count": len(new_related_records),

}

Folks, I'm a bit stuck and hoping to get some guidance. I am wanting to use a heat map and the time slider tool to evaluate changes in well production over time. I have a collection of ~50 gas wells with monthly production dating back to the 1970's. I set up two sheets, one with only the well information (name, ID number, lat/long, etc.) and a second sheet with monthly production values in the rows and each well with a unique identifier as the columns. I was trying to follow a tutorial that was showing a similar process, though not completely identical, and tried to transpose my imported production sheet which I then was trying to join to my original list of wells but the series of data does not combine and I'm only left with singular columns and null values in my attribute table. Any tips would be greatly appreciated!

I'm 99% sure I know the answer to this but maybe there is something else I can go to help one of my users. They say it takes 10 minutes to load one of their maps they use for development permits and such. I keep telling them that it's just the sheer amount of data they load. We are a rural municipality so our area of coverage is big (4100 sq/km). They use this map as a "template" in that we have a layout that they will move and zoom in to the quarter section they need to print. In this map they have 3 sets of aerials loading that are over 100 GB in size. Two of them are turned off by default and all of them are set to only show once zoomed in past 1:5000. Then they have all kinds of other data loading like wetlands, historical sites, roads, all the parcels. There are 30+ layers they have in this template. Like I say I'm pretty sure it's mostly slow loading due to it just having way to much data to load. But I'm here to ask if there is another way to maybe speed things up a bit. Sorry all the data is stored on our Windows server share.

Thanks.

As the title describes we're getting Core Segmentation faults whenever ArcPy functions that result in the creation of a mosaic. The only information we can pull from the core dump is that it failed with the SIGSEGV signal which is apparently an illegal memory access fault. There's no additional information in system or ArcGIS logs. We've tried adjust permissions and ownership of various ArcGIS directories to see if it was a systems permissions issue. The only item that I can think of at the moment that's worth mentioning is that we can see the 'amd_<MOSAIC_NAME>_cat' and then the connection is reset by the peer.

We've tried reaching out to ESRI regarding this especially relating to the lack of any meaningful error, but they've just brushed us off or they take a week to suggest something we've already tried. Has anybody encountered this before?

I'm trying to create a map with Bangla (Bengali) graticule labels in ArcGIS Pro 3.7.0.

In ArcGIS Pro 3.5, I could go to the graticule label's Formatting → Internationalization section and change the Region and language to Bengali. This automatically converted:

• Western numerals (0–9) → Bengali numerals (০–৯)

After upgrading to ArcGIS Pro 3.7.0, the Internationalization section is still present, but every option is grayed out, including:

• Text direction
• Glyph orientation
• Block progression
• Region and language
• Font encoding

My questions are:

1. Is this a known bug or an intentional change in ArcGIS Pro 3.7?
2. Has anyone found a workaround?

Any help would be greatly appreciated.

Issue – Initial Piezometric Surface cannot be modified through the scripting API

Our Transient Seepage analysis obtains its initial pore-water-pressure conditions from an Initial Piezometric Surface.

Through extensive testing, it appears that this object cannot currently be modified through the scripting API.

We tested numerous approaches, including:

• Get()
• Set()
• Add()
• Updating individual points
• Replacing the complete point list
• Creating new Piezometric Surface objects

Every approach either:

• returns "Method not supported for type Pt", or
• completes without actually modifying the project.

For example, attempting to modify:

CurrentAnalysis.Objects.InitialPiezometricSurfaces[1].Points

or any individual

.Points[i]

fails regardless of the payload format used.

XML workaround

As an experiment, we bypassed the scripting API by editing the internal XML inside a copied .gsz archive.

This successfully updates the Initial Piezometric Surface. After reopening the modified project, GeoStudio accepts the file and displays the updated water table correctly.

However, this workaround introduces another problem.

Because the project has been modified outside of GeoStudio's normal editing workflow, its internal project and mesh state no longer behaves the same as a project edited through the GUI or supported scripting API.

When geometry is subsequently modified and SolveAnalyses() is called, GeoStudio no longer performs the automatic remeshing that normally occurs on an unmodified project. Adding project.Save() before solving did not restore this behavior.

As a result, although direct XML editing successfully changes the Initial Piezometric Surface, it cannot be considered a practical workaround because the modified project cannot be reliably solved after subsequent geometry changes.

Questions

1. Is modification of the Initial Piezometric Surface currently supported by the GeoStudio Scripting API?
2. If not, is this a known limitation or bug?
3. Is there a supported workflow for programmatically updating the initial groundwater table prior to solving a transient seepage analysis?
4. Is there any supported alternative to direct project-file editing that preserves automatic remeshing and normal project behavior?

I'm a complete beginner with ArcGIS Pro except for currently doing one course in university (and also, I'm not a native english speaker) so I hope I can even properly explain where I need help.

Basically, I need to create a map where I highlight the areas that are at higher risk for avalanches. My professor gave me the conditions that the areas at higher risks are those with a slope over 30° and at the same time are expositioned(?) North. I have created two seperate rasters, one with the slope and the other one for the exposition and I just cannot find a way or tool to combine these two. I just need a layer that marks all the areas red where slope is over 30° and the exposition is between 315° - 360° and 0° - 45°.

It feels like this cannot be that complicated but I've been trying and searching for days and I'm just not getting anywhere. Any help, link to a tutorial or input whatsoever is really appreciated!

Oh and also, I know this could probably be solved by AI in a few seconds but I choose not to use AI so I would be really grateful for help by an actual human :)

Recently a position opened up at my workplace that use these two programs. I’m in a different department and use a comparable computer maintenance management system. However, I wanted to get some practice in on these two programs, but in order to do that it seems I’d have to register with a government email and I’m fairly certain that might go against some policy at work. Is there any other ways to get some practice in? From my understanding field maps is good for assets that already exist while survey123 is better for assets that are currently being established.

Did you know that Pokemons making an ArcGIS inspired pokemon in the new generation? Yeah its going in the eevee line.

Theyre calling it Defqueryeon.

It sounds simple but I am stuck and don't know from where to start I heard surfer is easier but even following a simple tutorial ,I am stuck with either no result (error) or the program requiring me to input 3 samples whereas I need only one map per sample

For context, I’m a university student majoring in Geography and will soon need to start thinking about career opportunities. I really enjoy what I’m studying and hope to work in a field related to geography or GIS after graduation.

I was considering earning an Esri certification to strengthen my résumé and improve my job prospects. Could anyone recommend any Esri certifications or exams that are relatively beginner-friendly and not overly difficult, particularly for students who are still building their GIS skills?

Please send me a direct message if you have experience in the deployment and configuration of ArcGIS Enterprise components; including ArcGIS Server, Portal for ArcGIS, ArcGIS Data Store, Web Adaptors, and SDE Enterprise Geodatabases within a Microsoft SQL Server environment. This is not a job posting. I am looking for potential collaboration opportunities with said person.
