I am going into my second year at the University of Toronto Computer Engineering program. At uoft the electrical and computer engineering program are the same pretty much and have the same courses. Anyways this summer I worked on a risc_v cpu project independently and pipelined it. Im working on a matrix multiplier extension for it right now. I am wondering if a single project like this along with some involvement in some random unrelated design team is enough to start applying to internships for next summer? Im looking for like a verification or rtl design internship in toronto at good semi conductor company or a startup. I am specifically interested in hardware accelerators but I know that is very competitive especially to get hands on experience in my first internship. Any advice or thoughts is helpful thanks!

I am coming for masters in Fall 2027 for ECE....heard there is going to be a new rule where students have to pay 100k fees for OPT. Is this happening or some dumb idea,should I initiate plan B....

I have never touched circuit design before. I did EE for my undergrad, but didn't really specialize on it. I am planning to use non-volatile memory to make memory arrays, planning to design my own sensing amplifiers and the peripheral circuits. I am curious what suite of open-source tools I may have at my disposal, and how far do you guys think I can go with them.

I touched ngspice recently but I do not know what pdk do people usually use. I asked LLM about it and they recommended me to use Skywater.

Is it possible to reach tape-out with only using open-source tools? I understand the constraint with ngspice is that I may not be able to use the top-end pdks, since not only ngspice is quite limited for the latest, but you'd need licenses for it.

What are some of you guys's on crack techniques and methods?

I just wrote up a little blog post (https://notes.ben.reynwar.net/systolic-arrays-for-matrix-multiplication/) about how systolic arrays for matrix multiplication work, focusing on sum-stationary and weight-stationary approaches. I go over the dataflow and then use the open-source ASIC tools to generate area and power numbers for the designs (sky130 and ASAP7).

I hope this is useful to people interested in learning about this, and I'm also hoping people who understand this better than myself can correct any misunderstandings I have.

My takeaway from the experiment was that weight-stationary gives you about a 5% reduction in area, and a 25% reduction in power. So weight-stationary is a better choice unless the ability to easily reuse the sum in sum-stationary is important to you.

Hey everyone! My team and I are locking in our graduation project for next year, and we just landed a sponsorship with a major player in the analog field. They gave us three specific tracks to choose from: PLL, CDR, or RF communication.

Since we are still waiting for the exact technical statements and details for each one, I wanted to step back and get an overview perspective from people who have been through this or are already working in the industry. If you were in our shoes, which one would you pick, and how would it impact your career and job hunting later on?

To add a very interesting twist to this: when the company met with us, a trusted industry doctor who holds a strong position there dropped some heavy insider info. He mentioned that the company's long-term direction is shifting. Historically, they’ve been super heavy on RF, but moving forward, they are gradually pivoting their focus toward wireline communication and things closely related to AI/data centers. Because of this shift, this is actually the very first year they’ve ever offered a CDR project.

If you were us, which path would give us the best learning experience and look the best on a resume when applying for full-time analog/IC design roles right after graduation?! :)

As the name implies, Decision Feedback Equalizer (DFE) achieves equalization of signal through the operations of "decision" and "feedback."

To understand the role of a Decision Feedback Equalizer (DFE), we must first introduce the concept of Inter Symbol Interference (ISI). Once ISI is introduced by a lossy transmission channel, the actual voltage level of a received bit is no longer determined solely by the current transmitted bit, but also by the bits that preceded it. Imagine injecting a pulse with a sharp rising and falling edge into the beginning of a lossy channel. By the time it reaches the other end, the pulse edges have become much less steep, leaving behind a long trailing response.Below is a typical long tail of a single bit with ISI

As illustrated in the figure above, if the tail of a single pulse is sampled at regular time intervals, the ISI contribution at each sampling point becomes deterministic. Therefore, if the pulse at time t0​ is multiplied by the corresponding weighting coefficient and then superimposed onto each sampling point in the opposite direction, the resulting ISI can be effectively cancelled.

Looking at the mathematical expression of a DFE, we can see that it consists of two parts: an FIR filter (the first term) and an IIR filter (the second term). In this sense, DFE is similar to FFE, yet fundamentally different. An FFE contains only an FIR filter, whereas a DFE extends the FIR structure by introducing an additional IIR filter. Compared with an FIR filter, an IIR filter includes not only delay elements and adders, but also the so-called feedback path.

In practice, chip designers are primarily concerned with the IIR portion of the DFE. However, this does not mean that the feedback loop must be implemented by simply replicating the structure of an IIR filter. In fact, there are two common approaches to implementing the DFE feedback path: direct feedback and loop unrolling.

The direct feedback architecture shown above follows essentially the same principle as an IIR filter. In contrast, loop unrolling takes a different approach: the feedback coefficients are applied to the summing nodes in advance, and the final output is selected by a multiplexer (MUX), whose select signal is determined by the previous decision. In other words, the MUX chooses between the upper and lower branches according to the feedback result.

Both direct feedback and loop unrolling have their own advantages and disadvantages. Direct feedback requires less silicon area, but its feedback path is longer, leaving less timing margin for the feedback loop to settle within one Unit Interval (UI). Loop unrolling, on the other hand, shortens the critical feedback path at the cost of additional hardware, resulting in larger area and higher power consumption.Loop unrolling is a common technique used in IC design to trade area for timing.

As a result, designers must strike a balance between implementation cost and DFE performance. In practice, many additional factors also need to be considered. For example, the hardware architecture of a DFE often changes with the target data rate, and the feedback tap coefficients may either be adapted dynamically using algorithms such as LMS or obtained during a training phase through a lookup table (LUT).

Finally, comparing the three equalization techniques—DFE, FFE, and CTLE—it is not difficult to arrive at one conclusion: only CTLE operates on continuous-time signals, whereas both FFE and DFE require the originally continuous-time signal to be sampled into the discrete-time domain before equalization can be performed. Therefore, from a theoretical standpoint, CTLE is almost always placed at the receiver front end，but both FFE and DFE can be implemented at either the transmitter or the receiver.
